The Checkline FTS-X is a complete Force Test System designed for precision measurement of push / pull force on a wide variety of applications. FTS-X offers USB data output and along with a complete software package (Windows XP Compatible, Not Compatible with Windows 7) to record and analyze your test data.
The Check-Line FTS-X consists of the FGV-XY Digital Force Gauge and FGS-100H Manual Hand-Wheel Test Stand.
1000 Hz Sample Rate
Selectable Auto-Shut Off
Accuracy of ±0.2%
Small Size
USB, RS-232 & Analog Outputs-- all included!
Automatic Calculation & Display of Statistics
200% Overload Capacity
3 Memory Modes
Rugged Die Cast Aluminum Housing & Rugged Construction
Built In User-Set Hi-Lo Alarm Limits
Reversible Display
Versatile bottom mounting plate accepts standard and custom-made attachments
Constant Linear Motion
consists of the FGV-XY Digital Force Gauge and FGS-100H Manual Hand-Wheel Test Stand
Includes calibration certificate
Sturdy, all steel construction
配件
FGV-RS232 RS232 9 Pin Serial output cable for FGV
FGV-ANALOG Analog output cable for FGV
FGS-LENGTH-H Digital Distance Gauge for FGS-100H Test Stand
Model | Capacity | Resolution |
Model | Capacity | Resolution |
FTS-5X | 5 lb | 0.001 lb |
FTS-10X | 10 lb | 0.01 lb |
FTS-20X | 20 lb | 0.01 lb |
FTS-50X | 50 lb | 0.01 lb |
FTS-100X | 100 lb | 0.1 lb |
