Standard Ranges up to 10,000 Lb-ft, Custom Ranges up to 100,000 available
The versatile ILTT Inline Torque Tester converts any non-impacting torque tool into a complete torque measuring & analyzing system, simply connect the tester to the square drive, attach a socket and measure clockwise or counter-clockwise torque. It can also be used for many other in-line torque measuring applications, drive sizes can be custom built with splines, key-ways and other design features to suit your application. Contact us to review your needs. Checkline ILTT
Internal NiMH rechargeable batteries provide 8-10 hours continuous use.
The Check-Line ILTT features an easy-to-use menu allowing fast adjustment of test parameters, and works in either one button or automatic modes of operation. Reliability and ease of use are enhanced with features such as: Sign Lock, Peak Blanking and Auto Clear.
Not for use with Impact Tools.
Custom versions available, contact our team to review your application details.
Available WIRELESS data output.
Bidirectional accuracy of ±1% of indicated reading
Eight (8) selectable engineering units: Oz.in., Lb.in., Lb.ft., Nm, cNm, KgfCm, gfCm, Kgfm
3 modes of operation: Track, Peak and 1st Peak
Rugged Aluminum Housing
NiMH rechargeable batteries provide 8-10 hours continuous use
Includes NIST-Traceable Calibration Certificate
Adjustable "auto-clear" for hands-free operation.
RS-232 Serial Output included for downloading data to PC's
Calibrated Range | 10-100% Full Scale, bi-directional |
Accuracy | ±1% of indicated (within calibrated range) |
Resolution | 4 Active Digits |
Overload Protection | |
Operating Modes | Track, Peak, 1st Peak |
Filtering | Selectable; 125Hz, 250Hz, 500Hz, 1000Hz, 1500Hz and 2000Hz |
Data Output | RS-232 |
Alarm Limits | Panel Mounted LED for Visual Alarm Limits |
Power | Internal NiMH battery, 9V Charger (included) |
Weight | Aproximately 3lbs depending on transducer |
Operating Temp | 32 - 120 °F (0-50 °C) |
Warranty | 1 Year |
Calibration Certificate | Includes NIST Traceable calibration certificate with data |
配件
TT-SOFT Data Transfer Software for TT Series, Includes USB Output Cable
TT-QC-CC Waterproof Carrying Case for ILTT
订货型号
Model | Range | Drive Size, Male Sq and Female Sq |
ILTT-100i | 10 - 100 lbf-in | 1/4" |
ILTT-250i | 25 - 250 lbf-in | 3/8" |
ILTT-500i | 50 - 500 lbf-in | 3/8" |
ILTT-100F | 10 - 100 lbf-ft | 1/2" |
ILTT-150F | 15 - 150 lbf-ft | 1/2" |
ILTT-250F | 25 - 250 lbf-ft | 1/2" |
ILTT-600F | 60 - 600 lbf-ft | 3/4" |
ILTT-750F | 75 - 750 lbf-ft | 3/4" |
ILTT-1000F | 100 - 1000 lbf-ft | 1" |
ILTT-2000F | 200 - 2000 lbf-ft | 1 1/2" |
ILTT-3000F | 300 - 3000 lbf-ft | 1 1/2" |
ILTT-5000F | 500 - 5000 lbf-ft | 1 1/2" |
ILTT-6000F | 600 - 6000 lbf-ft | 1 1/2" |
ILTT-10000F | 1000 - 10000 lbf-ft | 2 1/2" |
