MX-3 超声波壁厚计


The Dakota MX-3 Wall Thickness Gauge accurately measures wall thickness and the extent of corrosion of all metals, ceramics, glass and most rigid plastics - from only one side!



The Dakota Ultrasonics MX-3 can be used in a Single Thickness Reading mode or in a Scan mode , where the probe is dragged over a large measuring area. The minimum thickness reading recorded during the "scan" will be displayed.



The Dakota Ultrasonics MX-3 probe is waterproof and can be submerged in water. The gauge is impact-resistant and environmentally sealed to provide trouble-free operation under the toughest field conditions.



MX系列超声波测厚仪是美国DAKOTA ULTRASONICS公司推出的新一代超声波测厚仪。具有使用简单,功能齐全,体积小巧,可靠性高等特点。挤压铝制外壳,坚固耐用。



MX-3超声波测厚仪能精准测量所有金属、陶瓷、玻璃和最坚固的塑料的壁厚和腐蚀。

手持式超声波测厚仪是一种可信赖的精密测量工具,无需特别培训即可操作。MX-3探头具有防水线,将探头放到被测材料的上面,就可读出被测材料的厚度,或是沿被测材料的表面拖动探头,MX-3可以自动找出被测材料的最薄点。


  • Resolution of 0.001 inch (0.01 mm)

  • Large, backlit LCD display retains last reading

  • Simple operator controls virtually eliminate training

  • Special-purpose probes are offered for a variety of applications

  • Switch-selected units for inches or mm

  • For underwater surveying, probe cable lengths up to 50 feet are optionally

  • CE Certified

  • Includes NIST Calibration Certificate


测量范围
显示精度
探头频率
显示方式
校准
声速范围
扫描方式
电源

键盘

操作温度
尺寸

重量
包装

0.63-500mm(钢,取决于探头)
0.01mm
1MHz-10MHz
4位半数字液晶显示,带背光
对话式探头,自动校准
1250-10000m/s
每秒测量16个点,可以捕捉到最薄点
2节5号电池。连续使用时间达200小时,当电池供电不足时,显示器会闪烁报警,直至自动关机

6键防水、防油键盘

-30℃-50℃
63.5x114.3x31.5mm

300g
ABS工程塑料箱


订货清单

The Dakota Ultrasonics MX-3 is supplied as a complete kit with the gauge, probe, 4 oz. bottle of coupling fluid, 2 AA batteries, NIST Calibration Certificate, and Operating Instruction Manual - all in a foam-fitted carrying case.



订货型号

MX-3    Dakota MX-3 Thickness Gauge Complete Kit with T-102-2000 Probe, Z-112-0001



探头型号

型号

频率

探头晶片直径

测量范围

说明

PT-102-2000

5.0MHz

φ6.3mm

1.0~152mm

标准探头

PT-101-2000

5.0MHz

φ4.7mm

1.5~50mm

小管径探头

PT-104-0000

1.0MHz

φ12.7mm

3.8~50.8mm(铸铁中)

铸铁探头

PT-102-1000

2.25MHz

φ12.7mm

1.5~127mm

低频探头

PT-102-3200

7.5MHz

φ6.3mm

0.63~152mm

超薄探头

PT-104-2000

5.0MHz

φ12.7mm

1.27~500mm

超厚探头

PT-042-2000

5.0MHz

φ6.3mm

1.0~152mm

标准高温探头,最高340℃

PT-044-2000

5.0MHz

φ12.7mm

1.27~500mm

厚高温探头,最高340℃
