Frequency converters in the REOVIB MFS 158 series for vibratory conveyor technology offer the option of operating the vibratory conveyor at an optimal vibration frequency for the material - completely independently of the mains input frequency.
In addition, various sensor and valve logic links can be programmed. Devices in the REOVIB MFS 158 series are available with a max.output current of 4A, as IP20 versions for installation in control cabinets, and as IP54 standalone versions.
IP54：Input cable/output socket/Complete cable connection solution for mains, output and control connections.
Inexpensive frequency-control devices with the vital functionality
Frequency-control device for controlling a vibratory conveyor independently of the mains input frequency
Conveyor frequencies adjustable between 35...140 Hz
Mains voltage compensation with constant vibration amplitude
All settings can be made using the integrated display
Sinusoidal output current
Can be used on 110 V or 240 V mains, auto sensing.
User settings can be stored
With fill level/overflow control
Versions available in various protection classes and with various connection options
电源频率 | 50 / 60 Hz +/- 3 Hz |
输出电压 | 20…100 V / 40…210 V |
输出电流 | max. 4 A |
振动频率 | 35…140 Hz |
设置点数值 | Display, Potentiometer, 0…10V, 0…20 mA |
状态信号 | 24V DC |
启用 | 24 V DC，开关 |
传感器供电 | 24 V DC |
设置上下限 | 显示 |
缓启动 | 可调整（0-5秒） |
填充和溢出控制 | PNP, 24V DC |
电源电压补偿 | - |
合格证 | CE和RoHS |
防护等级 | IP20/IP54 |
订货型号
MFS 158-4A
MFS 158-6A
MFS 158-8A
MFS 158-16A
