微型测力传感器是一种小尺寸、低高度、全密封的测力传感装置。它适用于空间有限的场合，一般应用于高精度小量程称重场合，具有良好的抗侧、抗扭、抗偏等性能。
微测力传感器在受到外力作用后，粘贴在弹性体的应变片随之产生形变引起电阻变化，电阻变化使组成的惠斯登电桥失去平衡输出一个与外力成线性正比变化的电量电信号。美国Transducer Techniques ESP系列小型测力传感器应用：微型测力传感器适用于空间有限的测力，广泛应用于工业，科研等领域。。
ESP SERIES CAPACITY RANGES: 6, 10, 15, 20, 25, 30, 35 Kg.
The Transducer ESP Series is a economical, high accurate single point load cell. It is ideal for OEM applications such as electronic scales and weighing machines. The single point design is highly resistant to eccentric loading allowing direct mounting to the scale base and weighing platform. The ESP Series features a moisture proof sealant.
详情请联系我们
Rated Output (R.O.): 2.0mV/V ±10%
Nonlinearity: 0.02% of R.O.
Hysteresis: 0.02% of R.O.
Nonrepeatability: 0.02% of R.O
Zero Balance: ±1% of R.O.
Compensated Temp. Range: 14°F to 104°F
Safe Temp Range: 14°F to 140°F
Temp. Effect on Output: 0.002% of Load/°F
Temp. Effect on Zero: 0.002% of R.O./°F
Terminal Resistance: 350 ohms nominal
Excitation Voltage: 10 VDC (20 VDC max.)
Safe Overload: 150% R.O.
Max. Weighing Platform Size: 11.8” x 11.8”
配件
CAL-TEDS Plug & Play Option with Connector
订货型号
ESP-6 6 13
ESP-10 10 22
ESP-15 15 33
ESP-20 20 44
ESP-25 25 55
ESP-30 30 66
ESP-35 35 77
