Transducer Techniques TRT反作用扭矩传感器非常适合于测量电机支架、泵支架及机器支架中的反作用力或抑制扭矩。也可用于有限的旋转应用，如测量拧动螺母或制动器轴所需的扭矩。TRT设计配有法兰，可实现简易安装或改造。该传感器不仅坚固耐用可供工厂使用，而且其精度亦可供实验室所用。
TRT SERIES CAPACITY RANGES: 25, 50, 100, 200, 500 INCH LBS.
The TRT Series reaction torque sensors offer long term reliability due to non moving parts and state of the art bonded foil strain gages. Whenever possible, the best approach for precision torque measurements is via reaction torque sensing, eliminating high maintenance and high cost of slip rings, bearings and brushes.
非常适合用于在电机泵和机器支架中监控扭矩
法兰安装式，易于安装
可沿顺时针及逆时针方向测量扭矩
Rated Output (R.O.): 2 mV/V nominal
Nonlinearity: 0.1% of R.O.
Hysteresis: 0.1% of R.O.
Nonrepeatability: 0.05% of R.O.
Zero Balance: 1.0% of R.O.
Compensated Temp. Range: 60° to 160°F
Safe Temp. Range: -65° to 200°F
Temp. Effect on Output: 0.005% of Load/°F
Temp. Effect on Zero: 0.005% of R.O./°F
Terminal Resistance: 350 ohms nominal
Excitation Voltage: 10 VDC
Safe Overload: 150% of R.O.
订货型号
TRT-25 25 5,125 50 20 425
TRT-50 50 5,125 50 20 425
TRT-100 100 10,125 100 40 800
TRT-200 200 20,375 200 80 1,400
TRT-500 500 75,875 300 200 2,600
